FLIR E96 Thermal Imaging Camera

Description

FLIR E96 thermal imaging camera:
High accuracy and advanced technology for thermal inspections

The FLIR E96 Thermal Imager is the first gun camera with 640 × 480 pixel thermal resolution, designed for technicians to perform safe inspections in hazardous environments and quickly diagnose electrical or mechanical failures.

Equipped with interchangeable AutoCal™ lenses, this camera allows full coverage of near and far targets. In addition, its laser distance meter ensures precise focusing for accurate thermal measurements. Thanks to the FLIR Inspection Route feature, inspectors can plan and execute inspection routes efficiently, optimizing their time on large tasks.

Exceptional thermal imaging with the FLIR E96

With a thermal resolution of 640×480 pixels, the FLIR E96 generates sharp, detailed images. Its advanced UltraMax® and MSX® technologies enhance visual quality, providing vibrant, easy-to-interpret thermal images ideal for precision inspections.

AUTOCAL Smart Optics^TMfor greater versatility

The interchangeable, self-calibrating AutoCal™ lenses allow you to safely inspect electrical and mechanical hot spots and make it easy to check building envelopes quickly and efficiently. From telephoto to wide-angle lenses, the FLIR E96 adapts to different thermal inspection needs.

Work optimization with integrated reporting

The FLIR E96 Thermal Imager is designed to improve user efficiency. It incorporates path-tracking software, an integrated microphone for voice annotation, and advanced reporting tools, simplifying inspection documentation and facilitating decision making based on accurate thermal data.

FlexView™: One lens, two fields of view

Maximize the versatility of your FLIR E96 with the FlexView™ dual field-of-view lens. This innovative lens allows you to instantly switch between wide-area and telephoto scanning at the touch of a button, offering greater efficiency with every inspection without the need to manually swap lenses.

Workflow optimization with automated reporting

The FLIR E96 streamlines inspection documentation thanks to its integration with FLIR' s routing software(optional), automatic image upload to the FLIR Ignite cloud, and its built-in microphone for voice annotation. These advanced tools allow detailed reports to be generated quickly and efficiently, optimizing the user's workday.

Click here to download your free "12 things you need to know to choose a thermal imaging camera" guide.

We are Flir Gold Partner for Spain and Portugal.

Ref. 90201-0101, 90202-0101, 90203-0101, 90204-0101, 90207-0101, 90205-0101, 90206-0101

FLIR E96 thermal imaging camera

Discover the Exx series thermal imaging cameras

Technical data

Imaging and optical data	(For 24º lens)
Infrared resolution	640 × 480 pixels
UltraMax (super-resolution)	Yes
NETD	<40 mK @ 30°C (86°F)
Field of view	24° × 18°
Minimum focus distance	0.15 m (0.49 ft)
Minimum focus distance with MSX	0.5 m (1.64 ft)
Focal length	17 mm (0.67 in)
Spatial resolution (IFOV)	0.7 mrad/pixel
Available extra lenses	14° (AutoCal) 42° (AutoCal)
Lens identification	Automatic
f number	1.3
Image frequency	30 Hz
Focus	Continuous LDM One-shot LDM One-shot contrast Manual
Field of view match	Yes
Digital zoom	1-8× continuous

Detector data
Focal plane array/spectral range	Uncooled microbolometer/7.5-14 µm
Pitch detector	12 µm

Image presentation
Resolution	640 × 480 pixels (VGA)
Surface brightness (cd/m2)	400
Screen size	4 in
Viewing angle	80°
Color depth (bits)	24
Aspect ratio	4:3
Auto-rotation	Yes
Touchscreen	Optically bonded PCAP
Display technology	IPS
Cover glass material	Dragontrail®.
Programmable buttons	1
Viewfinder	No
Image adjustment	Automatic Automatic maximum Automatic minimum Manual

Image presentation modes
Infrared image	Yes
Visual image	Yes
Thermal fusion	No
MSX	Yes
Picture in Picture	Resizable and movable
Gallery	Yes

Measurement
Camera temperature range	-20 to 120°C (-4 to 248°F) 0 to 650°C (32 to 1202°F) 300 to 1500°C (572 to 2732°F)
Object temperature range and accuracy (for ambient temp. 15 to 35°C (59 to 95°F)	Range -20 to 120°C (-4 to 248°F): -20 to 100°C (-4 to 212°F): ±2°C (±3.6°F) 100 to 120°C (212 to 248°F): ±2%. Range 0 to 650°C (32 to 1202°F): 0 to 100°C (32 to 212°F): ±2°C (±3.6°F) 100 to 650°C (212 to 1202°F): ±2%. Range 300 to 1500°C (572 to 2732°F): ±2%.

Screening mode
Sampling average mode	Recommended temperature range: 30 to 45°C (86 to 113°F) in stable room temperature Accuracy (drift): ±0.3°C (±0.5°F)1

Inspection mode
FLIR Inspection route	Enabled in the camera

Measurement analysis
Spotmeter	3 in live mode
Area	3 in live mode
Automatic hot/cold detection	Auto-maximum/minimum markers within area
Measurement presets	No measurements Center spot Hot spot Cold spot User preset 1 User preset 2
Difference temperature	Yes
Reference temperature	Yes
Emissivity correction	Yes: variable from 0.01 to 1.0 or selected from materials list
Measurement corrections	Yes
External optics/windows correction	Yes

Alarm
Color alarm (isotherm)	Above Below Interval Condensation (moisture/humidity/dewpoint) Insulation
Measurement function alarm	Audible/visual alarms (above/below) on any selected measurement function

Set-up
Color palettes	Iron Gray Rainbow Arctic Lava Rainbow HC
Setup commands	Local adaptation of units, language, date and time formats
Languages	21

Service functions
Camera software update	Using USB cable or SD card

Storage of images
Storage media	Removable memory; SD card (8 GB)
Time lapse (periodic image storage)	10 seconds to 24 hours (infrared)
Remote control operation	Using USB cable or Wi-Fi
Image file format	Standard JPEG, measurement data included. Infrared-only mode

Image annotations
Voice	60 seconds built-in microphone and speaker (and via Bluetooth) on still images and video
Text	Text from predefined list or soft keyboard on touchscreen
Visual image annotation	Yes
Image sketch	Yes: on infrared images only
Sketch	From touchscreen
METERLiNK	Wireless connection (Bluetooth) to: FLIR meters with METERLiNK
Compass	Yes
Laser distance meter information	Yes
Area measurement information	Yes
GPS	Yes: location data automatically added to every still image and the first frame in video from built-in GPS

Video recording in camera
Radiometric infrared-video recording	RTRR (.csq)
Non-radiometric infrared-video recording	H.264 to memory card
Visual video recording	H.264 to memory card

Video streaming
Radiometric infrared-video streaming (compressed)	Over UVC
Non-radiometric video streaming (compressed: IR, MSX, visual, Picture in Picture)	H.264 (AVC) over RTSP (Wi-Fi) MPEG4 over RTSP (Wi-Fi) MJPEG over UVC and RTSP (Wi-Fi)
Visual video streaming	Yes

Digital camera
Resolution	5 MP with LED light
Focus	Fixed
Field of view	53° × 41°
Video lamp	Built-in LED light

Laser pointer
Laser alignment	Position is automatically displayed on the infrared image
Laser distance meter	Activated by a dedicated button
Laser	Class 2, 0.05-40 m (1.6-131 ft) ±1% of measured distance

Data communication interfaces
Interfaces	USB 2.0, Bluetooth, Wi-Fi, DisplayPort
METERLiNK/Bluetooth	Communication with headset and external sensors
Wi-Fi	Peer to peer(ad hoc) or infrastructure (network)
Audio	Microphone and speaker for voice annotation of images
USB	USB Type-C: data transfer/video/power
USB standard	USB 2.0 High Speed
Video out	DisplayPort
Video connector type	DisplayPort over USB Type-C

Radio
Operating frequency	Bluetooth + EDR/LE: 2402-2480 MHz WLAN 2.4 GHz: 2412-2462 MHz WLAN 5 GHz: 5150-5350 MHz (DFS: only slave mode) Note that frequency band 5150-5350 MHz is for indoor use only, see national regulations.
RF output (EIRP)	Bluetooth + EDR/LE: < 10 dBm WLAN: < 17 dBm
Antenna	Integrated PIFA antenna (gain: maximum 1.4 dBi)

Power system
Battery type	Rechargeable Li-ion battery
Battery voltage	3.6 V
Battery operating time	> 2.5 hours at 25°C (68°F) and typical use
Charging system	In camera (AC adapter or 12 V from a vehicle) or two-bay charger
Charging time (using two-bay charger)	2.5 hours to 90% capacity with charging status indicated by LEDs
Charging temperature	0°C to 45°C (32°F to 113°F), except for the Korean market: 10°C to 45°C (50°F to 113°F)
External power operation	AC adapter 90-260 V AC, 50/60 Hz, or 12 V from a vehicle (cable with standard plug-optional)
Power management	Automatic shut-down and sleep mode

Environmental data
Operating temperature range	-15 to 50°C (5 to 122°F)
Storage temperature range	-40 to 70°C (-40 to 158°F)
Humidity (operating and storage)	IEC 60068-2-30/24 hours/95% relative humidity 25-40°C (77-104°F)/two cycles
EMC	ETSI EN 301 489-1 (radio) ETSI EN 301 489-17 EN 61000-6-2 (immunity) EN 61000-6-3 (emission) FCC 47 CFR Part 15 Class B (emission)
Radio spectrum	ETSI AT 300 328 FCC Part 15.249 RSS-247 Issue 2
Encapsulation	IP 54 (IEC 60529)
Shock	25g (IEC 60068-2-27)
Vibration	2g (IEC 60068-2-6)
Drop	Designed for 2 m (6.6 ft)
Safety	EN/UL/CSA/PSE 60950-1

Physical data
Weight (including battery)	1 kg (2.2 lb)
Size (L × W × H)	278.4 × 116.1 × 113.1 mm (278.4 × 116.1 × 113.1 mm) (11.0 × 4.6 × 4.4 in)
Battery weight	140 g (4.9 oz)
Battery size (L × W × H)	150 × 46 × 55 mm (5.9 × 1.8 × 2.2 in)
Tripod mounting	UNC ¼″-20
Housing material	PCABS with TPE, magnesium
Color	Black

Warranty and service
Warranty	http://www.flir.com/warranty/

Shipping information
Packaging, type	Cardboard box
Packaging, contents	Accessory Box I: Power supply for battery charger Power supply, 15 W/3 A Printed documentation SD card (8 GB) USB 2.0 A to USB Type-C cable, 1.0 m USB Type-C to HDMI adapter, standard specification UH311 USB Type-C to USB Type-C cable (USB 2.0 standard), 1.0 m Accessory box II: Accessory box III: Front protection fastener Hand strap bracket, left Hand strap bracket, right Screws Torx T10 wrench Carabiner hook Front protection Hand strap Lanyard strap, camera Lens cap strap Wrist strap Battery (2 ea) Battery charger FLIR Thermal Studio Starter Hard transport case Infrared camera with lens Lens cap, front Lens cap, front and rear (only for extra lenses)
Packaging, weight	5.8 kg (12.8 lb)
Packaging, size	500 × 190 × 370 mm (19.7 × 7.5 × 14.6 in)
EAN-13	4743254004535
UPC-12	845188022266
Country of origin	Estonia
